I. INTRODUCTION

Friction conveyor is a chainless conveying equipment. It adopts relay friction drive technology, which has the characteristics of high efficiency, energy saving and environmental protection, and is widely used in automobile, steel, machinery, household appliances and other fields.

According to the track section form, it can be divided into two forms: double channel steel and H-beam; according to the use situation, it can be divided into two forms: suspension and ground.

II. Product features:

 1. The multi-point low-power motor drive can reduce energy consumption and save energy. Compared with the same transport capacity of chain conveyor, it can save 30-60% energy.

 2. Single-layer track is adopted to cancel the chain, save material and greatly reduce the noise of conveyor.

 3. Fast running speed, up to 5-50m/min, greatly improving work efficiency and meeting the needs of modern automobile production rhythm.

4. Friction drive is an ideal environmental protection equipment to avoid oil pollution caused by chain lubrication.

5. Using the building block structure to make transportation and installation more convenient. It is greatly speed up the construction progress and make maintenance is more convenient.

6. It can be seamlessly connected with the chain conveyor to form a variety of process systems.

III. Main performance parameters of the product

 ☆ Single vehicle rated load :2.0,5.0,10.0,15.0

 ☆ Drive motor power :0.1,0.2,0.4,0.55,1.5,2.2

 ☆ Straight rail standard segment length :6

 ☆ Horizontal bending rail radius: R≥1.5~3.0

 ☆ Arch curved rail :3.6,4.5,6.0

 ☆ climbing angle :≤30(additional chain greater than 10 degrees)

 ☆ speed :5~50

☆ Climbing Angle: ≤30 (more than 10 degrees with auxiliary chain)

☆ Speed: 5 ~ 50
